Rotary Scrape Surface Pulp Pasteurizer
Function
:
For heating Guava Pulp.
Construction
:
Square pipe Structure for Horizontally self-standing
Teflon Scrapers for proper stirring and preventing product from charring.
Inlet / Outlet connections will be three part union
Dial type temperature gauge mounted at discharge end spout.
Steam Piping fitted with BSP valve, Pressure Safety valve, Pressure Gauge, Air Vent, Condensate outlet connection complete with Bucket type Steam trap, Bypass Valve, Y strainer. For cooling necessary interconnecting piping.
Insulation which will be cladded with thin SS sheet.
Mechanical seal arrangement at feed end.
All flange gasket / Packing’s / Bushes etc. Food grade Teflon of suitable thickness.
M.O.C
:
SS 304
Capacity
:
100 kg to 5 Ton per hour
