Specification:

• Storage body is made of Poly-Urethane Foam panel
• Easy access to copper evaporator coil for washing and cleaning.
• Air flow axial fans in laminar pattern for quick heat transfer
• Control System :
  • Unit is operated by sensing temperature using RTD sensor for Product core (penetration) temperature, Microcontroller based Programmable Controller with LED display for temperature and time elapsed in a batch, where user can program and configure
  • Batch Time
  • Core Temperature set point
  • Compressor ON delay
  • OFF cycle Defrosting
• Cooling System :
  • Refrigerant-R 404a used.
  • Finned copper evaporation coil
  • Air cooled copper condenser for better thermal efficiency.
  • Low pressure and High pressure trip protection for compressor
  • Refrigeration system is split into two, creating one as a redundant (stand-by) system and so least downtime moreover switching only one system ON where chamber is half or partially loaded will save on running cost.
• Alarms : Audio alarm after each batch time elapsed
• Power Supply : Electrical supply 380 Volts AC and 50Hz, 3-phase ,4K watt power consumption
• Input Temperature of Product +35°C or Ambient
• Blast Freezer temperature gradient -18°C in less than 240 min*
