Inspection Conveyor
Function
:
For visual inspection and manual sorting of Fruits.
Construction
:
Belt supporting trough thro-out length of top side
Belt support on return side by PVC rollers and cleaning wiper
Square Section tubular rigid structure.
Feed hopper, discharge chute, Motor shroud, chain guards etc.
250 mm wide Side table with waste disposal chutes on both sides of conveyor to transfer material to bottom.
Fixed speed chain drive for conveyor.
Motor
:
Hindustan Make, Gearbox : Bonfiglioli / Equivalent make.
M.O.C
:
Wetted Parts SS 304
Input Capacity
:
100 Kg to 5000 Kg / Hr.
